LEVELING AND STABILIZATION
GROUND CONTROL
®
3.0 4 POINT ASSEMBLY
Power and
Ground
Harness
Hall Effect
Jacks; Left Rear
Snapper Pin
Rear
Sensor
Screw x4
Jack Mounting
Bracket x2
Landing
Gear x2
Bolt On
Pull Pin
Jack Mounting
Bolt & Nut x12
Carriage Bolt x4
Hall Effect
Jacks;
Right Rear
Landing Gear
Harnesses x2
Rear Jack
Harnesses x2
Top Lock Nut x4
Rear Sensor
Mounting Plate
LCD Touch Pad & Harness
Rear Sensor & Harness
4 Point Controller
