Lippert Components ground control 3.0 Service Manual

Rev: 05.23.2017 Page 5 Ground Control 3.0 Service Manual
Auto Level
After unhitching from tow vehicle and parking the vehicle at a safe distance away from the trailer, press the “ON/OFF”
button (Fig. 1K) and then press “AUTO LEVEL” (Fig. 1F).
NOTE: Once the automatic leveling cycle has been started, it is important that there is no movement in the trailer until
the trailer has completed the leveling process. Failure to remain still during the leveling cycle could have an
effect on the performance of the leveling system.
NOTE: In order for hitch recognition feature to function, the auto level sequence must be started with the front of the
trailer above level.
Auto Level Sequence
1. When Auto Level Sequence begins, the front of the trailer will lower slightly to a point below level.
2. Rear jacks will be grounded.
3. A side-to-side leveling sequence occurs.
NOTE: At this point on the 6 Point System, the two middle jacks are grounded to stabilize the trailer.
The two middle jacks do not level the trailer.
4. Each jack will perform a final grounding touch.
5. LCD will read “AUTO LEVEL SUCCESS” (Fig. 3).
6. LCD will then read “READY Jacks: Down” (Fig. 4A), and the green LED at the center of the four jack buttons will be
illuminated (Fig. 4B).
Fig. 3
Fig. 2
B
A
Fig. 4
A
B
NOTE: If the AUTO LEVEL sequence does not perform as described, place the system in manual mode and
test that the jacks operate correctly by pushing their coordinating buttons on the touch pad; i.e.
"FRONT" button operates only the front jacks, etc.
