Rev: 03.02.2017
Page 19
Ground Control 3.0 with OneControl
GROUND CONTROL 3.0 6 POINT ASSEMBLY
Power and
Ground
Harness
Hall Effect Jacks;
Left Rear/Mid x2
Snapper Pin
Rear
Sensor
Screw x4
Jack Mounting
Bracket x4
Landing
Gear x4
Bolt On
Pull Pin
Jack Mounting
Bolt & Nut x12
Carriage Bolt x4
Hall Effect Jacks;
Right Rear/Mid x2
Landing Gear
Harnesses x2
Rear Jack
Harnesses x2
Top Lock Nut x4
Rear Sensor
Mounting Plate
6 Point Controller
OneControl Touch Panel
Auto Leveling Control Touch Panel
Canbus Terminating
Resistor x2
4 Pin Pigtail Harness
Canbus Data Harness
Canbus Power
Connector
LEVELING AND STABILIZATION
Ground Control
®
3.0 6 Point Assembly
Rear Sensor
Rear Sensor Harness
