Product Component Descriptions
Frame
The lift system frame has four vertical c-channel rails (Fig. 1A). Each c-channel rail encases a chain drive and
two trolleys (Fig. 2) with attached brackets that travel between upper and lower limit switches.
Fig. 1
Fig. 2
Upper Trolley
Lower Trolley
