113
Figure 6.59 During Reverse Operation
23: Retain
24: During Regeneration
When the motor outputs during regeneration, the assigned output terminal closes.
25 : During Restart
When the drive attempts to clear a fault during restart, the assigned output terminal closes. If
the fault is cleared after restart, the output terminal opens. If the number of restart attempt
reaches the number set to P5-00 (Number of Auto Restart Attempts) without clearing a fault
successfully, the output terminal opens after the fault is triggered.
26 : Motor Overload Pre-Alarm (oL1)
When the motor overload level exceeds 90% of the detection level, the assigned output
terminal closes. Refer to P1-00 (Motor Protection Function Selection) for details.
27 : Drive Overheat Pre-Alarm (oH)
When the drive heatsink temperature exceeds the oH (overheat) detection level, the assigned
output terminal closes.
28 : Retain
29 to 34: Retain
35: During Frequency Output
When the drive is outputting frequency, the assigned output terminal closes.
The drive is during stop, baseblock or DC braking.
The drive is outputting frequency
