Step 2: Connecting EPS Connector
•
Unscrew the cap on the EPS port.
•
Insert the EPS cable into the EPS port on the
inverter until there is a “Click” sound.
6.4.2 Declaration for EPS Loads
The purpose of the EPS Loads Function is to enable certain house circuits to remain on
in the event of a power failure.
Make sure that the combined power required for all devices connected to this output does
not exceed the power rating of the inverter.
The hybrid inverter can supply a continuous 5000VA output (max 5500VA for 10s) on
EPS side. And the inverter has self-protection derating at high ambient temperature.
Accepted loads as below:
• Inductive Load: Max 1.5KVA for single inductive load, max 2.5KVA for total
inductive load power.
• Capacitive load: Total capacitive load (like computer, switch power etc.) power
≤3.0KVA
• Do not connect loads that are dependent on a stable energy supply for a reliable
operation.
• Do not connect the loads that may cause very high start-up current surges, such as
air-conditioner, high-power pump, and hair drier.
• Due to the condition of the battery itself, battery current might be limited by some
factors, including but not limited to the temperature and weather.
