LMF Clima LCM - Menu Pr9 List; Menu Root; Time Range; Day Assignment

Electronic Control "LCM" User Manual
firmware 0.06 Rev.02 EN 5/ 15
EN
5 Menu  list
On this menu it is possible to set the clock program range, visualize input and output status and access to service
settings.
5.1. Menu root
Press together Esc and “et
฀
Clock time program range setting
฀
Day program assignment
฀
Night
฀
Service (password)
฀
Input / output status
฀
Alarm history฀
5.2. Time range
 (program setting)
฀
Program 1: Start time range 1
P1
08:00
฀
Program 1: End time range 1
P1
12:00
฀
Program 1: Cooling set range 1
P1
26.0°C
฀
Program 1: Heating set range 1
P1
20.0°C
฀
Program 1: Start time range 2
P1
14:00
฀
Program 1: End time range 2
P1
17:00
฀
Program 1: Cooling set range 2
P1
26.0°C
฀
Program 1: Heating set range 2
P1
20.0°C
฀
Program 2: Start time
P2
08:00
฀
Program 2: End time
P2
17:00
฀
Program 2: Cooling set
P2
26.0°C
฀
Program 2: Heating set
P2
20.0°C
5.3. Day
 (programs assignment)
฀
Monday
P1
฀
Tuesday
P1
฀
Wednesday
P1
฀
Thursday
P1
฀
Friday
P1
฀
Saturday
P2
฀
Sunday
P4
For each day of the week it is possible to select between 4 programs:
 Program P1: the unit is turned On in two different time range (for example one in the morning and one in the
afternoon)
 Program P2: the unit is turned On in a single time range
 Program P3: the unit is turned On all the day
 Program P4: the unit is turned Off all the day
