Electronic Control "LCM" User Manual
firmware 0.06 Rev.02 EN 8/ 15
EN
5.9. Parameter ()
 (password) 1
  (antifreeze defrost)
Min
Max
฀฀
Antifreeze set point
5.0°C
-5.0°C
15.0°C
5.10. Parameter ()
 (password) 1
 ฀
Min
Max
฀
Supply fan: pressure sensor set point
100Pa
50Pa
- - -Pa
฀
Return fan: pressure sensor set point
100Pa
50Pa
- - -Pa
฀
Fan: CO
2
sensor set point
700ppm
500ppm
2000ppm
฀
Manual fan/damper: Minimum speed
33%
0%

฀
Manual fan: Medium speed
67%
฀
฀
฀
Manual fan: Maximum speed
100%
฀
100ppm
฀
Auto fan: MED speed differential with temp sensor
2.0°C
0.1°C
10°C
฀
Auto fan: MAX speed differential with temp sensor
2.0°C
0.1°C
10°C
฀
Auto fan/damper: MED speed differential with CO
2
sensor
100ppm
1ppm
1000ppm
฀
Auto fan: MAX speed differential with CO
2
sensor
100ppm
1ppm
1000ppm
฀
Return speed correction
0%
-50%
50%
฀
Boost working time (minimum 1min. maximum 15min.)
10min
00:00
04:15
฀
Filter alarm time (if 0= off, if >0= on)
0 day
0
999
฀
Filter alarm reset
OFF
฀
PIR working (da 0 a 30 minuti)
5min
00:00
04:15
5.11. Parameter ()
 (password) 1
 ฀฀
Min
Max
฀
Cooling valve proportional band
2.0°C
0.1°C
10°C
฀
Heating valve proportional band
2.0°C
0.1°C
10°C
฀
Post-heating valve proportional band
2.0°C
0.1°C
10°C
฀
Valve integral time
0sec
0
3200
฀
Heating differential
2.0°C
0.1°C
10°C
฀
Plant start-up time (only for winter)
00:10min
00:00
01:00
฀
Min. damper opening
50%
0%
100%
฀
Free-cooling differential
1.0°C
0.1°C
10°C
฀
Free-heating differential
1.0°C
0.1°C
10°C
฀
Free-cooling Hysteresis
0.5°C
0.1°C
1.5°C
฀
Adiabatic cooling set-point
30°C
20.0°C
40.0°C
฀
Fresh air temperature set point for automatic changeover
15.0°C
5.0°C
30.0°C
฀
Season changeover differential
10.0°C
0.1°C
20.0°C
฀
Winter dehumidification enabling setpoint
10.0°C
0.1°C
30.0°C
5.12. Parameter ()
 (password OEM)
  (Reserved for OEM technician)
