Electronic Control "LCM" User Manual
firmware 0.06 Rev.02 EN 15/ 15
EN
Address
read
Description Input-Output
Value
Um
Default
Min
Max
8192
State On-Off digital input (DI1) 0 = Off; 1 = On
0
0
0
1
8960
Regulation Probe
17.5
°C
175
-500
1100
8961
External Damper 0 = Off; 1 = On
0
0
0
1
8962
Current Return Fan Speed
0.0
%
0
0
1000
8963
Current Supply Fan Speed
0.0
%
0
0
1000
8964
Three Point Cold or Changeover Valve Estimated Position
100.0
%
0
0
1000
8965
Three Point Hot Valve Estimated Position
100.0
%
0
0
1000
8966
Pump 1 COLD OR CHANGE 0 = Off; 1 = On
1
0
0
1
8967
Pump 2 HOT 0 = Off; 1 = On
1
0
0
1
8968
Heater Status 0 = Off; 1 = On
0
0
0
1
8971
Outdoor Temperature
11.2
°C
112
-500
1100
8975
Outlet Pressure
72
Pa
8976
Inlet Pressure
0
Pa
8977
CO2
0
ppm
8978
Exhaust Temperature
6.7
°C
67
-500
1100
8979
Antifreeze Temperature
10.0
°C
100
-500
1100
8980
Supply temperature
16.0
°C
160
-500
1100
8987
Actual Setpoint
20.0
°C
200
50
350
8988
On Off Status
0
0
0
1
8989
Boost Status
0
0
0
1
8990
Mixing Chamber Opening Status
100.0
%
0
0
1000
Address
read
Description
Allarm
0= Not Active
1= Active
2=Manual Reset
Value
Um
Default
Min
Max
9000
Outlet Probe Error
0
0
0
1
9001
Outdoor Probe Error
0
0
0
1
9002
SKW Probe Error
0
0
0
1
9003
Filter Alarm
0
0
0
1
9004
Heater Alarm (Manual Reset)
0
0
0
2
9005
Inlet Pressure Probe Error
0
0
0
1
9006
Outlet Pressure Probe Error
0
0
0
1
9007
CO2 Probe Error
0
0
0
1
9009
Fan Alarm (Manual Reset)
0
0
0
2
9011
Antifreeze Probe Error
0
0
0
1
9013
Expansion Communication Alarm
0
0
0
1
9014
Antifreeze Alarm
0
0
0
1
9015
Fire Alarm (Manual Reset)
0
0
0
2
9016
Min Hot Water Temperature Alarm
0
0
0
1
9017
Clock Error
0
0
0
1
9018
SKW Probe AIR2 Error
0
0
0
1
9019
SKW Communication Alarm
0
0
0
1
9020
Return Probe Error
0
0
0
1
9021
Note:
(divided 10, °C) divide the value by 10, the result is in degree Celsius with one decimal place (Es: 175= 17.5°C)
(divided 10, %) divide the value by 10, the result is in percentage with one decimal place (Es: 505= 50.5%)
(HH:MM) minutes starting from midnight where 0= 00:00 e 1439= 23:59 (In example: 120= 02:00; 1170= 19:30)
