Gocator Line Profile Sensors: User Manual
Gocator Device Files • 400
Element Type Description
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RefSide 32s Setting for reference side to use.
MaxGapWidth 64f Setting for maximum gap width (mm).
LeftEdge
ProfilePanelEdge
Element for left edge configuration.
RightEdge
ProfilePanelEdge
Element for right edge configuration.
Measurements\Gap
Gap/Flush
measurement
Gap measurement.
Measurements\Flush Gap/Flush
measurement
Flush measurement.
Measurements\LeftGapX Gap/Flush
measurement
Left Gap X measurement.
Measurements\LeftGapZ Gap/Flush
measurement
Left Gap Z measurement.
Measurements\LeftFlushX Gap/Flush
measurement
Left Flush X measurement.
Measurements\LeftFlushZ Gap/Flush
measurement
Left Flush Z measurement.
Measurements\LeftSurfaceAngl
e
Gap/Flush
measurement
Left Surface Angle measurement.
Measurements\RightGapX Gap/Flush
measurement
Right Gap X measurement.
Measurements\RightGapZ Gap/Flush
measurement
Right Gap Z measurement.
Measurements\RightFlushX Gap/Flush
measurement
Right Flush X measurement.
Measurements\RightFlushZ Gap/Flush
measurement
Right Flush Z measurement.
Measurements\RightSurfaceAn
gle
Gap/Flush
measurement
Right Surface Angle measurement.
