Gocator Line Profile Sensors: User Manual
Gocator Device Files • 401
Element Type Description
EdgeType 32s
Edge type:
0 – Tangent
1 – Corner
MinDepth 64f Minimum depth.
MaxVoidWidth 64f Maximum void width.
SurfaceWidth 64f Surface width.
SurfaceOffset 64f Surface offset.
NominalRadius 64f Nominal radius.
EdgeAngle 64f Edge angle.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Edge region.
ProfilePanelEdge
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Axis
(Gap measurement only)
32s
Measurement axis:
0 – Edge
Gap/Flush Measurement
