3- CHAPTER 3: PROCEDURES
3-16
Sequence:
The carriage unit retracts toward the home position,
simultaneously, the PLC waits to detect the proximity
switch SQ5 and the servo amplifier looks for the
torque to build up after hitting the mechanical stop.
Once the home position is set, the HOME PAGE will
reappear on the remote control station.
REFERENCE POINT
POSITIONING
IN PROGRESS...
Procedure complete.
