LNS Quick Load Servo 80 - Battery Replacement

CHAPTER 4: SOFTWARE
QUICK LOAD SERVO 65/80
4-5
Battery Replacement
Conditions:
- Bar feed power on.
Procedure:
Step 1: In the electrical cabinet, open the PLC cover.
Step 2: Take the battery support out of the bay labeled "BATT".
Step 3: Replace the battery with an identical type. Check that the battery is in the right direction.
Step 4: Insert back the battery support in its bay. Close the PLC cover and the electrical cabinet.
Procedure Complete.
