CHAPTER 6: SPARE PARTS
6-2
Recommended Spare Parts List
As an extended courtesy, a list of recommended spare parts has been compiled for the end user. The list
consists of mechanical and electrical parts that over time may become faulty due to everyday wear on the
item. For machines that are running production during multiple shifts or even 24/7, keeping an inventory
of these spare parts can vastly minimize downtime. Keeping an inventory can also be very cost effective
since shipping costs can escalate immensely, especially in cases where rush delivery is necessary.
Designation Article No Description
QS 1 4.242 Main disconnect switch
SQ 1 4.391 Proximity switch, loading table in lower position
SQ 3 4.474 Positioning optical cell
SQ 4 4.391 Proximity switch, diameter selection fingers in origin position
SQ 5 4.391 Pusher in home position switch
SQ 10 4.763 Cover closed safety switch
SQ 11 4.763 Magazine cover closed safety switch
SQ 12 4.763 Retraction system safety switch
QUICK LOAD SERVO 65/80
