The following information outlines the factory procedures for preliminary installation of the Lockformer
Vulcan Cutting Machine. Appropriate Lockformer reference and assembly drawings accompany
this manual. See section 4.
1. SAFETY
Voltages used on this machine are potentially hazardous. Therefore, all equipment must be installed
and maintained in accordance with local requirements and National Electrical Codes. Also see the
SAFETY FIRST section of this manual.
2. UNCRATING
The machine’s crating should ensure that all components arrive in good order, but as the assemblies
are uncrated, check all contents with the packing list for possible damage from shipping. If anything
shows up missing, or damaged, notify the carrier in writing at once. It is the responsibility of the
receiver to file any claims for damage against the carrier. As each assembly or detail is unpacked,
it should be placed in a suitable dry area and have its preservative removed by use of a nontoxic fluid.
Avoid the use of trichlorethylene or perchloroethylene, and ensure that the cleaning area is well
ventilated.
3. LOCATION OF MACHINE
The Vulcan needs a floor space where vibration is at an absolute minimum. Precision operation is
necessary for accurate cutting, thus avoid areas where the transmission of any heavy vibration,
(from trucks, factory equipment, etc.) may occur nearby.
Choose a site for the Vulcan near gas and electrical outlets, and if possible, near any related
production lines, for manufacturing efficiency. Material handling is also important, so be sure to
provide space for stockpiling material and moving it by hoist, truck, or other means. Adequate lighting
and ventilation must be available for safety reasons, as noted in the safety material.
DO NOT ANCHOR THE TABLE TO THE FLOOR. A Lockformer installation
technician will level the equipment and secure it to the floor.
4. INCOMING POWER SUPPLY FOR PLASMA UNIT
The proper cable setup procedures are as follows:
1. Locate the Plasma Unit (consult Lockformer Service Department).
2. Use as short a power cord as is practical to connect the machine to its power supply.
Do not use
a cable that is too short - use one that leaves some slack so it cannot stretch or break during use.
Do not coil the cables. Follow all applicable local, state, and national codes.
3. Route AC power wires to keep them away from any auxiliary power; this includes solenoids, control
boxes, etc.
4. Connect the Vulcan to an AC power source for its use
exclusively. Do not operate any other
machinery from the same power line as the Vulcan!
Preliminary Installation... Page 1
