Loewe Connect 26 SL, Connect 22 SL User Manual

- 102
english
Connections (max. equipment)
Designation Type Function / Signal
Mains socket 220-240V ~ 50/60Hz Supply voltage
HDMI type A (2x) Digital Video/Audio IN: Digital video
(1
and audio
D-SUB 15-pole Video IN: PC/STB video signal
(1
Mini Scart
Video IN:
Video OUT:
Audio IN:
Audio OUT:
CVBS (VHS/8 mm)
RGB
CVBS (VHS/8 mm)
L/R
L/R
RJ-45 Ethernet: Network interface
USB type A (2x) USB 2.0 (500mA): Multimedia files/software update
Jack 3,5 mm Audio IN: L/R
Cinch Digital Audio OUT (SPDIF): Digital audio
Jack 3,5 mm Audio OUT: L/R
IEC socket 75 Ohm / 5 V / 60 mA: Cable analogue / DVB-T / DVB-C
F socket 75 Ohm 13/18 V / 400 mA: DVB-S/S2
CI slot COMMON INTERFACE Slot for CA module
Jack 3,5 mm Headphones 32–2000 Ohm
Cinch (white/red) R - AUDIO - L L (white) / R (red)
Cinch (yellow) VIDEO CVBS (VHS/8 mm)
Technical data
(1
For compatible picture signals, see table on page 101.

Loewe Connect 26 SL, Connect 22 SL Specifications

General

Brand	Loewe
Model	Connect 26 SL, Connect 22 SL
Category	LCD TV
Language	English
