Reference 55-85
User manual
137
Technical Data
Technical data
Changes of technical data and design of the equipment reserved.
Loewe device type:
Reference 85 Reference 75 Reference 55
Part number: 54435xxx 54434xxx 54433xxx
EU energy efficiency class:
see enclosed energy label or under www.loewe.tv/int/my-loewe
Screen diagonal: 216 cm / 85 inch 189 cm / 75 inch 140 cm / 55 inch
Power consumption On-Mode (max.)
(Audio output 1/8 of the maximum value):
515 W 350 W 205 W
Power consumption On-Mode (home)
(1
:
Annual energy consumption
(1
:
see enclosed energy label or under www.loewe.tv/int/my-loewe
Power consumption Standby Mode:
Power consumption when set is switched off:
0,40 W
0 W
0,40 W
0 W
0,38 W
0 W
Resolution / Picture format: Ultra HD 3840 x 2160 px / 16:9
Display technology: LCD with Direct-LED-Backlight
LCD with Edge-LED-Backlight
Viewing angle (horizontal / vertical): 178° / 178°
Device dimensions without stand (W x H x D): 194,0 x 115,5 x 8,9 cm 171,7 x 102,9 x 8,9 cm 125,9 x 76,6 x 6,1 cm
Weight without stand (approximate): 96,5 kg 75,2 kg 36,7 kg
Ambient temperature: 5° C – 35° C
Relative humidity (non-condensing): 20 – 80%
Air pressure: 800 – 1114 hPa (0 – 2000 m above sea level)
Chassis designation: SL 420
Power supply: 220 V – 240 V/50–60 Hz
Tuner: terr./cable:
Satellite:
VHF/Hyperband/UHF
4 levels: 13/18V/22kHz / 16 levels: DiSEqC 1.0 / single-cable system: EN 50494
Range: terr./cable:
Satellite:
Terr./cable: 45 MHz up to 860 MHz
Satellite: 950 MHz up to 2150 MHz
Station storage locations incl. AV and radio: 6000
TV standards: analogue:
digital:
B/G, I, L, D/K, M, N
DVB-T/T2, DVB-C, DVB-S/S2 (UHD via DVB to max. 60 Hz)
Colour standards: SECAM, PAL, NTSC, NTSC-V, PAL-V (60 Hz)
Sound standards: analogue (FM):
analogue (NICAM):
digital (MPEG):
Mono, Stereo, Dual channel
Mono, Stereo, Dual channel
Mono, Stereo, Dual channel, PCM, Dolby Digital, Dolby Digital Plus, Dolby Digital Pulse, Dolby
Virtual Speaker, Dolby Pro Logic II, Dolby TrueHD, Dolby MS11, DTS, DTS HD
Audio output power (sine / music): 2 x 30W / 2 x 60W
Acoustic speaker concept: Soundbar
Teletext: TOP / FLOF / HiText (Level 2.5)
Page memory: 2000
LAN: Standards supported: 10 Mbit/sec Ethernet (10Base-T) / 100 Mbit/sec Fast Ethernet (100Base-T)
WLAN: Standards supported:
Frequency range used:
Types of encoding that are supported:
IEEE 802.11a/b/g/n, 802.11ac
2400-2483,5 MHz and 5150-5725 MHz
WEP 64 and 128 Bit (ASCII and HEX), WPA PSK, WPA2 AES
Bluetooth:
Bluetooth protocols:
Wireless transmission 2.4 GHz, 10 m transmission range
A2DP SRC, A2DP SNK, HID
Home networking standard: Universal Plug and Play Audio / Video (UPnP AV)
File formats supported
(2
: Pictures:
Audio:
Video:
JPEG, PNG
MP3, M4A (AAC LC), WMA (without lossless), FLAC, WAV (PCM), Ogg Vorbis
AVI (MPEG-1/2, XviD, AC3, MP3), WMV (WMV9, VC-1, WMA9, WMA Pro),
MP4 (XviD, H.264/MPEG-4 AVC, AAC LC), MOV (H.264/MPEG-4 AVC, AAC LC),
MKV (H.265/HEVC, H.264/MPEG-4 AVC, AC3), FLV (H.264/MPEG-4 AVC, H.263, MP3,
AAC LC),
MPG (MPEG-1, MPEG Audio), TS/PS (MPEG-2, H.264/MPEG-4 AVC, MPEG2 Audio,
AC3)
, VOB (MPEG-2, MPEG2 Audio, AC3)
H.264/MPEG-4 AVC upto Profil High (Level 4.2)
(1
The energy consumption per year is calculated on the basis of a daily four-hour operation of the TV set on 365 days. The actual energy consumption will depend on the
way the TV set is used. On-Mode (home) values less than 100 W must have decimal places (,0).
(2
For the playability of the individual formats no guarantee can be given.
