Signals via AV (PC IN) / HDMI
The following table shows the compatible signals which may be
represented by your TV set using the appropriate adapter at the AV
connection (PC IN) or at the HDMI connections (HDMI1, HDMI2,
HDMI3, HDMI 4 UHD).
Set the output signal on your device so that it matches one of the
signals in the table.
Please note that not all signals may be represented at every HDMI
socket or at AV (PC IN).
Format Horizontal
x Vertical
Frame
frequency
Connection
480i60 720 x 480i 60Hz PC IN, HDMI 1-3
576i50 720 x 576i 50Hz PC IN, HDMI 1-3
480p60 720 x 480p 60Hz PC IN, HDMI 1-4
576p50 720 x 576p 50Hz PC IN, HDMI 1-4
720p50 1280 x 720p 50Hz PC IN, HDMI 1-4
720p60 1280 x 720p 60Hz PC IN, HDMI 1-4
1080i50 1920 x 1080i 50Hz PC IN, HDMI 1-4
1080i60 1920 x 1080i 60Hz PC IN, HDMI 1-4
1080p24 1920 x 1080p 24Hz PC IN, HDMI 1-4
1080p25 1920 x 1080p 25Hz PC IN, HDMI 1-4
1080p30 1920 x 1080p 30Hz PC IN, HDMI 1-4
1080p50 1920 x 1080p 50Hz PC IN, HDMI 1-4
1080p60 1920 x 1080p 60Hz PC IN, HDMI 1-4
VGA 640 x 480 60Hz PC IN, HDMI 1-4
SVGA 800 x 600 60Hz PC IN, HDMI 1-3
XGA 1024 x 768 60Hz PC IN, HDMI 1-3
WXGA 1360 x 768 60Hz HDMI 1-3
SXGA 1280 x 1024 60Hz PC IN, HDMI 1-3
3840 x 2160p 24Hz HDMI 1-4
3840 x 2160p 25Hz HDMI 1-4
3840 x 2160p 30Hz HDMI 1-4
3840 x 2160p 50Hz HDMI 4
3840 x 2160p 60Hz HDMI 4

Technical Data
Signal input groups
In your TV set the signals are sorted in various signal input groups
according to their source. In addition to the source, the type of signal
is also distinguished.
For each signal input group, there are individual values for the picture
settings.
Signal
group name
Signal source/Signal type
SD Analog cable analogue, interfaces AV, AVS, PC IN
(1
(SD)
SD Digital DVB (SD), DR+ (SD), MPEG-Encoder
SD Media
Player
full screen display of SD videos via USB, Network,
VOD and media centre (incl. HbbTV media centre)
SD HDMI Playback of SD video via HDMI, e.g., DVD player
HD Analog PC IN
(1
(HD)
HD Digital DVB (HD), DR+ (HD)
HD Media
Player
full screen display of HD videos via USB, Network,
VOD and media centre (incl. HbbTV media centre)
HD HDMI Playback of HD videos via HDMI, e.g., Blu-Ray player
3D HD 3D playback of HD videos (analogue or digital)
3D SD 3D playback of SD videos (analogue or digital)
3D Media
Player
full screen display of 3D videos (SD/HD) via USB,
Network, VOD and media centre (incl. HbbTV media
centre)
3D HDMI Playback of 3D videos via HDMI, e.g., 3D Blu-Ray
player
Photo Player Playback of Photos via USB and network
Browser Display of Web sites in the Browser (incl. Media apps)
VGA PC IN
(1
(PC) or HDMI (PC)
(1
with VGA adaptor on AV connection.

Loewe Reference 85 Specifications

General

Brand	Loewe
Model	Reference 85
Category	TV
Language	English
