Dear Customer,
Thank you for choosing a Lofrans product. Lofrans is a leader company in the production and worldwide distribution of nautical systems
manufactured according to the most modern technologies, in compliance with international regulation requirements and the most
important certifying bodies. All our products are manufactured with excellent materials suited for operations in marine environments and
are subject to continuous checks to improve the qualitative levels and make them without any manufacturing defects. Together with such
requirements, Lofrans anchor windlasses are a synthesis of reliability and efciency, by guaranteeing the maximum performances during
each phase of mooring, even in the most difcult. With a Lofrans product, years of reliable operations are guaranteed.
Lofrans declines any liability for possible inaccuracies due to print errors in this manual and reserves the right to introduce any changes
deemed appropriate.
For this reason, Lofrans does not guarantee the accuracy of the manual after the date of issue and declines all liability for possible errors
and omissions.
1 INTRODUCTION 3
1.1 Purpose of the manual 3
1.2 Assistance 3
1.3 Receipt and storage 3
2 INSTALLATION 3
2.1 Contents of the package 3
2.2 Recommended accessories 3
2.3 Installing the magnet on the anchor windlass 3
2.4 Installing the magnetic sensor for
vertical shaft anchor windlasses 4
2.5 Installing the magnetic sensor for
horizontal shaft anchor windlasses 4
2.6 Installing the chain counter 4-5
3 ELECTRICAL SYSTEM 5
4 TECHNICAL DATA 5
5 MENU 5
5.1 Starting up 5-6
5.2 Chain counter setting menu 6
5.3 Measurement menu 6
5.4 Alarm and functions menu 7
5.5 Settings menu 7
5.6 Language menu 7
5.7 Sensor calibration menu 8
Lofrans©copyright, 2015. All rights reserved.
PRODUCT COMPLIANT WITH CE REGULATIONS
TABLE OF CONTENTS
5.8 Table 1 - Standard and Project X. series sensor 8
5.9 Table 2 - 1000 – 1500 – 2000W
Project series sensor 9
5.10 Check menu 9
6 USΕ 10
6.1 Measurement reset 10
7 TROUBLESHOOTING 10
8 WIRING DIAGRAM 10
9 WARRANTY CONDITIONS 11
