57
THIS MANUAL IS PROPRIETY OF ECOWIND by LOMBARDINI - ALL FORMS OF REPRODUCTION, PARTIAL OR OTHERWISE, IS STRICTLY PROHIBITED
G
B
CT
Fig. 119
Fig. 118
CT
3 - ASSEMBLY AND INSTALLATION
Step Description
6 After mounting the system, attach the plastic pipe
covering CT (supplied) as shown in the gure 118, by
boring the cab rear using a 3.5mm bit and attaching
with the supplied self-threading screws .
Step Description
7 NB: It is recommended to use a light thread of silicone
not supplied on the contact surface of the covering
CT to the sheet metal of the cab to optimise the seal
see g 119.
Use silicone only
