Lorex LNZ32P12 series User Manual

Technical Specifications
8
Image Sensor 1/3", 2.1MP CMOS (LNZ32P12)
1/2.7", 2.1MP CMOS (LNZ32P12S)
Video Format NTSC / PAL
Effective Pixels 1920 (H) x 1080 (V)
Resolution Up to 1080p
Range 360° Pan (Endless); 0–90° Tilt (Auto-Flip)
Pan/Tilt Speed Max 300°/Sec Pan; Max 200°/Sec Tilt.
Zoom
12x Optical Zoom & 16x Digital Zoom
Min. Illumination 0.05 Lux in Color; 0.005 Lux in Black and White
Lens / Lens Type Auto Focus / 5.1 – 61.2mm F1.6 – F2.3
Field of View (Horizontal) 4° ~ 51° (LNZ32P12)
5° ~ 60° (LNZ32P12S)
Scan System
Progressive
Synchronization
Internal
Iris Auto Iris
S / N Ratio >55dB (AGC Off)
Termination
RJ45 10 M / 100M Ethernet
Power Requirement PoE+ (Power over Ethernet, Class 4)
1
; 24V AC
Power Consumption Max. 750mA
Operating Temperature Range 14°F ~ 140°F / -10°C ~ 60°C (LNZ32P12)
-22°F ~ 140°F / -30°C ~ 60°C (LNZ32P12S)
Operating Humidity Range
Within 90%RH
Indoor/Outdoor Both (IP66)
2
Weight (Camera Alone)
Weight (Camera & Wall Mount)
4.0lbs / 1.8kg
5.7lbs / 2.6kg
#LX400020; r.41770/42005; en-US
26
1. Compatible with all Lorex HD NVRs except for LNR200 & LNR300 Series.
2. Not intended for submersion in water. Installation in a sheltered location recommended.
