Lovol TE304 - Page 89

Technical specifications
Items Unit
LOVOL Europard
TE254 TE304 TE354
4 24.24 22.80/24.00 25.09/26.91
Drive
System
Clutch
——
Double disks, dry, disk spring pressed, constant engaged, metal and
ceramic friction plate, in-dependent dual action clutch
Gearbox
——
Mechanical transmission case composed of two shafts; 8F+8R shuttle gear
shifting or synchronizer with shuttle gear shifting (8 forward gears and 8
reverse gears), sliding gear shifting;
Rear
Axle
Central Drive
——
Bevel Gear
Differential
——
Closed-Type，4 Bevel Planet Gears
Differential Lock
——
Dental Clutch
Rear Final Drive
——
Built-In, Single Stage Straight Teeth Column Gear
Traveling
System
Frame
——
Half frame
Tire
Pressu
re
Front Wheel
kPa
120
～
150
Rear Wheel
120～150/150～180(11.2-24、12.4-24)
Tire
Specif
ication
Front Wheel
—— 6.0-16 6.5-16 7.5-16
Rear Wheel
—— 9.5-24 11.2-24 12.4-24
Steering
System
Way
——
Front-wheel steering (maximum 40°, toe-in 4-10mm)
Steering gear
——
Cycloid rotary valve all hydraulic steering gear
Brake
System
Traveling Brake
——
Shoe Brake
Parking Brake
——
Parking Brake
Trailer Brake Control
——
Charging Brake
Work
Device
Hydraulic System Type
——
Open-Core, Independent-Type
Hydraulic Pressure Oil Pump
L/min 24 36
Distributor
——
Side Valve Type
Oil
Tan
k
Diameter× Stroke
mm
70（75、85）×105
Form
Single-Action
Overhang Mechanism
——
Three-Points Rear Suspension,ⅠType
Tilling Depth Adjustable
Way
——
Position Control And Float Control
Max Lifting Force（frame
kN ≥5.2 ≥6.2 ≥7.2
Open Pressure Of System
Safety Valve
MPa
17.5～18.0
Hydrauli
c Output
Form —— Post Built-In
Quantity —— Single-Way Hydraulic Output(Optional Two-Way Valves)
Specificatio
n
——
M22×1.5 Or NPT1/2
Power
Output
Shaft
Form
——
Rear positioned, non-independent-Type
Specification
——
Φ35，6 rectangular Tooth Clutch Spline Shaft（OptionalΦ35，8 Rectangular
Tooth Clutch Spline Shaft）
Revolution
r/min
540/1000（
Optional 540/760）
Traction Traction
Form
——
Rocker rod
84
