Appendixes
Item
No.
Code Bearing Name and Specification Installatin position Quantity
23
GB/T 276
Bearing 6205-Z
Transfer case
11.4 Tractor chassis seal:
Table 11-4 Tractor chassis seal schedule
Part Specification Installation position Quantity
1 GB/T3452.1
O ring 10.6X2.65
Transmission case and
operation
1
2
TL01372040028
Framed rubber oil sealing
PD35X62X12
Transmission case and
operation
2
3
GB/T 3452.1
O ring 15X2.65 Differential lock
2
4
GB/T 3452.1
O ring 33.5X3.55 Differential lock
1
5 TS09580010009 O ring 23.6X2.9-M27X2 Dipstick of rear axle housing 1
6 GB/T9877.1
Skeleton oil seal
FB60X90X12D
Axle shaft assembly 4
7
GB/T3452.1 O ring 30x2.65 PTO
1
8
GB/T9877.1 oil seal B40x62x8D PTO
1
9
GB/T3452.1 O ring 80x2.65 PTO
1
10
GB/T 3452.1 O ring 15x2.65G
Brake assembly 1
11 GB/T9877.1
oil seal B50X70X8D
Brake assembly 2
12
GB/T3452.1 O ring 10.6X2.65G PTO operation
1
13
GB/T3452.1 O ring 45.0X3.55G Transfer case 1
14
TL01421010022 oil seal FB25X42X10D Transfer case 2
15 GB/T 3452.1
O ring 15.0X2.65G
Transfer case 1
16 GB/T3452.1
O ring 46.2X3.55G
Drive shaft
1
17 GB/T 3452.1
O ring 53.0X3.55G
Drive shaft
1
18
GB/T9877.1 oil seal FB25X40X7D Drive shaft 2
19
GB/T 3452.1 O ring 48.7X3.55G Drive shaft 1
20
GB/T 3452.1 O ring 11.2X1.80G Operation of transfer case
11.5 LOVOL series tractor matching implement
Table 11-5-1 LOVOL series tractor matching implement
