18
GlobalMap 5200c Cable Connections.
Network
socket
Power/Data
socket
Display unit
power cable
Data cable
NMEA 2000
Power cable
Extension
cable
Ethernet (future
enhancement)
Double T
connector
Extension
cable
LGC-3000
120-ohm
terminator
120-ohm
terminator
