Register Name
Register
Address
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
set_point_0
384
0x0180
[0x00DC]
set_point_1
385
0x0181
[0x0000]
set_point_2
386
0x0182
[0x0000]
set_point_3
387
0x0183
[0x0000]
set_point_4
388
0x0184
[0x0000]
set_point_5
389
0x0185
[0x0000]
set_point_6
390
0x0186
[0x0000]
set_point_7
391
0x0187
[0x0000]
set_point_8
392
0x0188
[0x0000]
set_point_9
393
0x0189
[0x0000]
set_point_10
394
0x018A
[0x0000]
set_point_11
395
0x018B
[0x0000]
set_point_12
396
0x018C
[0x0000]
set_point_13
397
0x018D
[0x0000]
set_point_14
398
0x018E
[0x0000]
set_point_15
399
0x018F
[0x0000]
These registers contain the values of up to 16 set points.
All registers are 16 Bit signed values. Depending on the tepwi_unit specified with the
corresponding set point configuration register at address 320 to 351 (Table 29 at Page 41)
the value needs to be scaled as described in Table 39 at Page 51 to achieve the desired
result.
Table 32: Set Points
