3.4.4 Model Information Registers (read only)
These registers are set at production time and contain specific information about the specific
model and the default button print layout.
Description
Register
Address
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Button Print Layout
L1
L2
L3
L4
L5
L6
default_print_
touch_button_0
528
0x0210
[0x0004]
[0x0004]
[0x0004]
[0x0004]
[0x0004]
[0x0004]
default_print_
touch_button_1
529
0x0211
[0x0000]
[0x0006]
[0x0006]
[0x000A]
[0x0006]
[0x0006]
default_print_
touch_button_2
530
0x0212
[0x0000]
[0x0000]
[0x0008]
[0x0008]
[0x000A]
[0x000A]
default_print_
touch_button_3
531
0x0213
[0x0001]
[0x0001]
[0x0001]
[0x0001]
[0x0001]
[0x0001]
default_print_
touch_button_4
532
0x0214
[0x0005]
[0x0005]
[0x0005]
[0x0005]
[0x0005]
[0x0005]
default_print_
touch_button_5
533
0x0215
[0x0000]
[0x0007]
[0x0007]
[0x000B]
[0x0007]
[0x0007]
default_print_
touch_button_6
534
0x0216
[0x0000]
[0x0000]
[0x0009]
[0x0009]
[0x000B]
[0x000B]
default_print_
touch_button_7
535
0x0217
[0x0002]
[0x0002]
[0x0002]
[0x0002]
[0x0002]
[0x0008]
default_print_
external_button_0
536
0x0218
[0x0000]
default_print_
external_button_1
537
0x0219
[0x0000]
default_print_
external_button_2
538
0x021A
[0x0000]
default_print_
external_button_3
539
0x021B
[0x0000]
assembly_matrix – defines the components that can be used:
0 – component not installed
1 – component installed
Button Print Layout – describes which symbols are printed on the front panel and on the
external buttons by default. The following symbols are defined:
0x0000 – none
0x0001 – menu
0x0002 – occupancy
0x0003 – reserved
0x0004 – temp_up
0x0005 – temp_down
0x0006 – fan_up
0x0007 – fan_down
0x0008 – light_on
0x0009 – light_off
0x000A – blinds_up
0x000B – blinds_down
Table 36: Model Information Registers
