LOYTEC L-STAT - Specifications; Physical Specifications

L-STAT User Manual 58 LOYTEC
Version 1.0 LOYTEC electronics GmbH
8 Specifications
8.1 Physical Specifications
Operating Voltage 24 VDC ±10 %
Power Consumption see Table 41
In rush current up to 4A @ 24 VDC
Operating Temperature (ambient) 0C to +50C
Storage Temperature –10C to +60C
Humidity (non condensing) operating 10 to 90 % RH @ 50C
Humidity (non condensing) storage 10 to 90 % RH @ 50C
LCD Backlight Lifetime 50,000 hours
Enclosure 94.5 x 110 x 19.5 (W x H x D)
Environmental Protection IP 30 (enclosure)
Installation Europe: switch box Ø 60mm
US: switch box 4” x 2”
LCD brightness
LSTAT-800-Gx-Lx &
LSTAT-801-Gx-Lx
LSTAT-802-Gx-Lx
100%
0.8W
0.93W avg., 1.8W max.
0%
0.09W
0.22W avg., 1.1W max.
Table 41: Power Consumption
8.2 Sensor Specifications
Ambient Temperature Sensor type: CMOS
range: -40 – 125 °C
resolution: 0.1 °C
accuracy: ± 0.5 °C (5 – 60 °C)
