L-STAT User Manual 59 LOYTEC
Version 1.0 LOYTEC electronics GmbH
Relative Humidity Sensor type: capacitive
range: 0 – 100 %R.H.
resolution: 0.1 %R.H.
accuracy: ±2 %R.H. @ 25 °C, 20 – 80 %R.H.
±3 %R.H. @ 25 °C, 0 – 20 %R.H. &
80 – 100 %R.H.
CO
2
Sensor type: NDIR
range: 0 – 2000 ppm
resolution: 1 ppm
accuracy: ±30 ppm or ±3 % of reading
warm up time: < 2 min (operational),
10 min (max. accuracy)
self calibration: the sensor will perform a self
calibration routine within the first
24 hours of continuous operation.
After calibration has finished the
sensor will operate at the defined
accuracy.
Occupancy Sensor max. range: 5 m
detection zones: 64
opening angle: 94° H, 82° V (see Figure 14)
temperature difference to background: 4°C
TOP-View: SIDE-View:
Figure 14: Occupancy Sensor Opening Angle
Infrared Receiver protocol: NEC
carrier: 38 kHz @ 950 nm
Apple remote control compatible
