L-STAT User Manual 13 LOYTEC
Version 1.0 LOYTEC electronics GmbH
2 Quick-Start Guide
2.1 Hardware Installation
Please refer to the L-STAT installation sheet for further information on dimensions,
mounting and wiring.
Figure 2 shows the back view of the device with the connection terminals for Modbus, 24 V
DC-Supply and external buttons. The four external buttons share a common GND
connection which is not connected to the negative 24 V input terminal!
Figure 2: Back View LSTAT-80x-Gx-Lx
