L-STAT User Manual 47 LOYTEC
Version 1.0 LOYTEC electronics GmbH
Register Name
Register
Address
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
offset_value_0
480
0x01E0
[0x0000]
offset_value_1
481
0x01E1
[0x0000]
offset_value_2
482
0x01E2
[0x0000]
offset_value_3
483
0x01E3
[0x0000]
offset_value_4
484
0x01E4
[0x0000]
offset_value_5
485
0x01E5
[0x0000]
offset_value_6
486
0x01E6
[0x0000]
offset_value_7
487
0x01E7
[0x0000]
offset_value_8
488
0x01E8
[0x0000]
offset_value_9
489
0x01E9
[0x0000]
offset_value_10
490
0x01EA
[0x0000]
offset_value_11
491
0x01EB
[0x0000]
offset_value_12
492
0x01EC
[0x0000]
offset_value_13
493
0x01ED
[0x0000]
offset_value_14
494
0x01EE
[0x0000]
offset_value_15
495
0x01EF
[0x0000]
These registers are used to define offsets for display values when displaying a value from
a built in sensor. These registers can either be written via Modbus or can be edited in
CALIBRATION-mode by the system administrator.
All registers are 16 Bit signed values. Depending on the tepwi_unit specified with the
corresponding display value configuration register at address 256 to 287 (Table 28 at
Page 39) the value needs to be scaled the same as the corresponding display value as
described in Table 39 at Page 51.
Table 35: Offset Values
