Appendix 4 Common Area Parameter of iS7 Inverter
Appendix 4-1
Appendix 4 Common Area Parameter of iS7 Inverter
4.1 Common Area Parameter (for Monitoring)
Address Parameter Scale Unit R/W Detailed Description
0x0300 Inverter Model - - R iS7 : 000Bh
0.75kW: 3200h
1.5kW: 4010h 2.2kW: 4022h
3.7kW: 4037h 5.5kW: 4055h
7.5kW: 4075h 11kW: 40B0h
15kW: 40F0h 18.5kW: 4125h
22kW: 4160h 30kW: 41E0h
37kW: 4250h 45kW: 42D0h
0x0301 inverter capacity - - R
55kW: 4370h 75kW: 44B0h
110kW: 46E0h 160kW: 4A00h
220kW: 4DC0h 315kW: 53B0h
375kW: 5770h
200V single phase open air cooling : 0220h
200V 3 phase open air cooling : 0230h
200V single phase forced cooling : 0221h
200V 3 phase forced cooling : 0231h
400V single phase open air cooling : 0420h
400V 3 phase open air cooling : 0430h
400V single phase forced cooling : 0421h
0x0302
Inverter input
voltage / power
supply type
(single phase, 3
phase)
/ cooling method
- - R
400V 3 phase forced cooling : 0431h
0x0303
inverter S/W
version
- - R
Ex) Ver1.02 : 0102h
0x0304 Reserved - - - -
BIT15
BIT14
BIT13
BIT12
0 : normal status
4 : Warning status
8 : Fault status(operates according to set
value of PRT-30 Trip Out Mode)
BIT11
BIT10
BIT9
BIT8
None
BIT7
BIT6
BIT5
BIT4
1:speed search 2:accelerating
3:steady speed 4:decelerating
5:decelerating stop 6:H/W OCS
7:S/W OCS 8:dwell operating
BIT3
BIT2
BIT1
0x0305
Inverter operating
status
- - R
BIT0
0 : stop
1 : forward operating
2 : reverse operating
3 : DC operating(0 speed control)
BIT15
BIT14
BIT13
BIT12
BIT11
BIT10
BIT9
BIT8
operating command source
0:keypad
1:communication option
2:App/PLC 3:built-in485
4:terminal block 5:reserved
6:Auto 1 7:Auto 2
BIT7
BIT6
BIT5
0x0306 inverter operating,
frequency
command source
- - R
BIT4
- frequency command source
0:keypad speed 1:keypad torque
2~4:Up/Down operating speed
5: V1 6: I1 7: V2 8: I2
