LS Industrial Systems SV-iS7 PLC User Manual

Appendix 4 Common Area Parameter of iS7 Inverter
Appendix 4-2
Address Parameter Scale Unit R/W Detailed Description
BIT3
BIT2
BIT1
BIT0
9: Pulse 10: built-in485
11:communication option 12: App(PLC)
13: Jog 14: PID
15~22 : Auto Step
25~39 : sequential frequency
0x0307 keypad S/W
version
- - R (Exercise) 0x0100 : Version 1.00
0x0308 keypad Title
version
- - R 0x0101 : Version 1.01
0x0309
~0x030
F
Reserved - - - -
0x0310 output current 0.1 A R -
0x0311 output frequency 0.01 Hz R -
0x0312 output RPM 0 RPM R -
0x0313
motor feedback
speed
0 RPM R -32768 [RPM] ~ 32767 [RPM] (direction)
0x0314 output voltage 0.1 V R -
0x0315 DC Link voltage 0.1 V R -
0x0316 output power 0.1 kW R -
0x0317 output Torque 0.1 % R -
0x0318 PID reference 0.1 % R -
0x0319 PID feedback 0.1 % R -
0x031A
Show poles of
first motor
- - R Show poles of first motor
0x031B
Show poles of
second motor
- - R Show poles of second motor
0x031C
Show poles of
selected motor
- - R Show poles of selected motor
0x031D Select Hz/rpm - - R 0 : Hz unit 1 : rpm unit
0x031E
~0x031
F
Reserved - - - -
BIT15 None
BIT14 None
BIT13 None
BIT12 None
BIT11 None
BIT10 P11 (Expansion IO Terminal Input 3)
BIT9 P10 (Expansion IO Terminal Input 2)
BIT8 P9 (Expansion IO Terminal Input 1)
BIT7 P8 (Basic IO Terminal Input 8)
BIT6 P7 (Basic IO Terminal Input 7)
BIT5 P6 (Basic IO Terminal Input 6)
BIT4 P5 (Basic IO Terminal Input 5)
BIT3 P4 (Basic IO Terminal Input 4)
BIT2 P3 (Basic IO Terminal Input 3)
BIT1 P2 (Basic IO Terminal Input 2))
0x0320
Digital Input
Information
- - R
BIT0 P1 (Basic IO Terminal Input 1)
BIT15 None
BIT14 None
BIT13 None
BIT12 None
BIT11 None
BIT10 None
BIT9 None
0x0321 Digital Output
Information
- - R
BIT8 None
