Appendix 4 Common Area Parameter of iS7 Inverter
Appendix 4-5
Address Parameter Scale Unit R/W Detailed Description
BIT9 None
BIT8 None
BIT7 None
BIT6 None
BIT5 None
BIT4 Gate Drive Power Loss
BIT3 Watchdog-2 Error
BIT2 Watchdog-1 Error
BIT1 EEPROM Error
BIT0 ADC Error
BIT15 None
BIT14 None
BIT13 None
BIT12 None
BIT11 None
BIT10 None
BIT9 Auto Tunning Failure
BIT8 Keypad Lost
BIT7 encoder mis-connected
BIT6 encoder mis-mounted
BIT5 DB
BIT4 FAN Operation
BIT3 Lost command
BIT2 Inverter Overload
BIT1 Underload
0x0334
Warning
Information
- - R
BIT0 Overload
0x0335
~0x033
F
Reserved - - - -
0x0340 On Time Date - Day R Days when inverter is ON
0x0341 On Time Minute - Min R Minutes with total days on time subtracted
0x0342 Run Time Date - Day R Total days when the inverter operates the motor
0x0343 Run Time Minute - Min R Minutes with total days Run time subtracted
0x0344 Fan Time Date - Day R Total days when the fan operates
0x0345 Fan Time Minute - Min R Minutes with total days Fan time subtracted
0x0346
~0x034
9
Reserved - - - -
0x034A Option 1 - - R
0x034B Option 2 - - R
0x034C Option 3 - - R
0: None 1,2: Reserved
3: Profibus 4,5,6: Reserved
7: RNet 8,9: Reserved
10: PLC 20: External IO-1
23: Encorder
To Next Page
