LS Industrial Systems SV-iS7 PLC - 4.2. Inverter Common Area Parameter (Control)

Appendix 4 Common Area Parameter of iS7 Inverter
Appendix 4-6
4.2. Inverter Common Area Parameter (Control)
Address Parameter Scale Unit R/W Detailed Description
0x0380 frequency
command
0.01 Hz R/W Command Frequency Setting
0x0381 RPM command 1 RPM R/W Command RPM Setting
BIT3 Changed from 0 to 1: Free-run to stop
BIT2 Changed from 0 to 1: Trip Reset
BIT1
0: Reverse Command
1: Forward Command
BIT0
0: STOP Command
1: RUN Command
0x0382
operating
command
- - R/W
Ex) Forward run command:0003h,
Reverse run command:0001h
0x0383 accelerating time 0.1 sec R/W Acceleration time setting
0x0384 decelerating time 0.1 sec R/W Deceleration time setting
BIT1
5
0: OFF Command 1: ON Command
(COM65:Virtual DI16)
BIT1
4
0: OFF Command 1: ON Command
(COM64:Virtual DI15)
BIT1
3
0: OFF Command 1: ON Command
(COM63:Virtual DI14)
BIT1
2
0: OFF Command 1: ON Command
(COM62:Virtual DI13)
BIT11
0: OFF Command 1: ON Command
(COM61:Virtual DI12)
BIT1
0
0: OFF Command 1: ON Command
(COM60:Virtual DI11)
BIT9
0: OFF Command 1: ON Command
(COM59:Virtual DI10)
BIT8
0: OFF Command 1: ON Command
(COM58:Virtual DI9)
BIT7
0: OFF Command 1: ON Command
(COM57:Virtual DI8)
BIT6
0: OFF Command 1: ON Command
(COM56:Virtual DI7)
BIT5
0: OFF Command 1: ON Command
(COM55:Virtual DI6)
BIT4
0: OFF Command 1: ON Command
(COM54:Virtual DI5)
BIT3
0: OFF Command 1: ON Command
(COM53:Virtual DI4)
BIT2
0: OFF Command 1: ON Command
(COM52:Virtual DI3)
BIT1
0: OFF Command 1: ON Command
(COM51:Virtual DI2)
0x0385
virtual digital
input control
(0:Off, 1:On)
- - R/W
BIT0
0: OFF Command 1: ON Command
(COM50:Virtual DI1)
BIT5
0 : OFF Command 1 : ON Command
(Expansion IO, OUT36:
Q4 Define is “None”)
BIT4
0 : OFF Command 1 : ON Command
(Expansion IO, OUT35: Q3 Define is
“None”)
0x0386
digital output
control
(0:Off, 1:On)
- - R/W
BIT3
0 : OFF Command 1 : ON Command
(Expansion IO, OUT34: Q2 Defineis
“None”)
