Appendix 4 Common Area Parameter of iS7 Inverter
Appendix 4-7
Address Parameter Scale Unit R/W Detailed Description
BIT2
0 : OFF Command 1 : ON Command
(Basic IO, OUT33: Q1 Define “None”)
BIT1
0 : OFF Command 1 : ON Command
(Basic IO, OUT32: Relay2 is “None”)
BIT0
0 : OFF Command 1 : ON Command
(Basic IO, OUT31: Relay1 is “None”)
0x0387 Reserved - - - -
0x0388 PID reference 0.1 % R/W PID reference command released
0x0389
PID feedback
value
0.1 % R/W PID feedback value
0x038A
~0x038
F
Reserved - - - torque command
0x0390 Torque Ref 0.1 % R/W forward motor ring torque limit
0x0391
Fwd Pos Torque
Limit
0.1 % R/W forward regenerative torque limit
0x0392
Fwd Neg Torque
Limit
0.1 % R/W reverse motor ring torque limit
0x0393
Rev Pos Torque
Limit
0.1 % R/W reverse regenerative torque limit
0x0394
Rev Neg Torque
Limit
0.1 % R/W torque Bias
0x0395 Torque Bias 0.1 % R/W PID reference command released
0x0396
~0x039
9
Reserved - - - -
0x039A Anytime Para CNF-20 of iS7 value setting
0x039B Monitor Line-1 CNF-21 of iS7 value setting
0x039C Monitor Line-2 CNF-22 of iS7 value setting
0x039D Monitor Line-3 CNF-23 of iS7 value setting
