23
TRACTOR SEAT MOUNTING
▶ PRE-Assembly
Reversivle seat removal
Maintenance hazard!
Before performing any maintenance or inspection:
-position machine on a firm, level surface
-turn off the engine
-remove the ignition key
-secure the machine (Wheels chocked)
-disconnect the wiring
(Unless instructed otherwise)
Failure to comply could result in death or serious injury.
Remove the four M10 bolts (1) securing the seat
bracket (2).
Remove the seat by disconnecting the seat
harness connector (1).
