TRACTOR SEAT MOUNTING
▶ Assembly
Reversible seat installation
1. Remove the seat cushion (1) by removing four M8
bolts (2).
Handle all parts carefully. Do not place your hands or fingers between parts. Use Personal Protective
Equipment (PPE) as indicated into this manual, including protective goggles, gloves, and safety
footwear.
Failure to comply could result in death or serious injury.
Note : New reversible seat kit
(1) Spacer (FR) (2) Spacer (RR)
(3) M8 Wrenches bolt (4) Reversible seat bracket
2. Rotate the base (1) of the reversible seat slightly as
shown in the photo.
