SERVICE MANUAL(CYLINDERS)
Dipper stick cylinder
(1) Nut
(2) Piston
(3) Cylinder tube
(4) Cylinder head
(5) Piston rod
Dipper stick cylinder consists of a nut (1),
piston (2), cylinder tube (3), cylinder head
(4), piston rod (5) and other parts as
shown in the figure above. They are
single-rod double acting cylinder in which
the reciprocating motion of the piston is
controlled
Cylinder specifications
