Jumper and Connector Description for the 9750 Controller Card Family
www.lsi.com/channel/products 31
J6B2 Battery
backup
unit
connector
20-pin connector.
Connects the optional intelligent battery
backup unit (LSI iBBU07) directly to the
controller.
Table 8: Jumpers and Connectors for 9750-4i4e
(continued)
Jumper/
Connector
Type Description
