LSIS H100 Troubleshooting Manual

1. Basic Checklist
13
(Up-Down operation)
D
Frequency command during DOWN operation
(Up-Down operation)
S
Frequency command during STOP operation
(Up-Down operation)
O
FBus Option frequency command
J
Jog frequency command
R
Internal 485 frequency command
1 ~7
Multi-step frequency command
3
Multi
Function
Key Setting
UserGrp
SelKey
Used to register parameters as a user group in the parameter
mode or delete parameters in the user group.
4
Inverter
Operating
Status
STP
Motor stopped
FWD
Operating forward
REV
Operating reversely
Forward command given
Reverse command given
DC
DC outputting
WAN
Warning
STL
Stalling
SPS
Speed Searching
OSS
Software Over Current controlled
OSH
Hardware Over Current controlled
TUN
Auto Tuning
PHT
Pre-heat
FIR
Fire mode operation
SLP
Sleep mode operation
LTS
Load tuning
CAP
Capacity diagnostics
PCL
Pump clean
