3. Maintenance
40
Replacement of 5.5~22kW
1) Remove the fan cover by pressing the hook located by the arrow.
2) Disconnect the fan wire and remove the fan from the inverter.
Replacement of 30~75kW
1) Remove ① screws to separate the fan bracket from the inverter.
2) Disconnect the fan wire and remove ② screws.
