LSIS Starvert iG5A Series User Manual

1) It is indicated when setting bit 2 of F59 as 1
2) Set F63 to 1 to display this parameter.
LED
display
Address for
communication
Parameter
name
Min/Max
range
Description
Adj.
during run
Factory
defaults
Function group 1
A238
[Overload
0 ~ 1
trip select]
A239
[Overload 30 ~ 200
trip level] [%]
[Overload 0 ~ 60
A23A
trip time] [Sec]
A23B
[Stall prevention
0 ~ 7
select]
[Stall prevention 30 ~ 200
A23C
level] [%]
[When Stall
A23D
prevention during
0~1
deceleration, voltage
limit select
[Save up/down
A23F
frequency select]
0 ~ 1
A240
[Save up/down
frequency]
A241
[Up-down mode
0~2
select]
A242
[Up-down step 0~400
frequency] [Hz]
A246
[Draw run mode
0~3
select]
A247 [Draw rate] 0~100[%]
This parameter turns off the drive output when motor is
overloaded.
This parameter sets the amount of overload current.
The value is the percentage of H33- [Motor rated current].
This parameter turns off the drive output when the F57-
[Overload trip level] of current flows to the motor for F58-
[Overload trip time].
This parameter stops accelerating during acceleration,
decelerating during constant speed run and stops decelerating
during deceleration.
This parameter sets the amount of current to activate stall
prevention function during Accel, Constant or Decel run.
The set value is the percentage of the H33- [Motor rated current].
In Stall prevention run during deceleration, if you want to limit
output voltage, select 1
This parameter decides whether to save the specified frequency
during up/down operation.
When 1 is selected, the up/down frequency is saved in F64.
If ʻSave up/down frequencyʼ is selected at F63, this parameter
saves the frequency before the drive stops or decelerated.
We can select up-down mode among three thing
0
Increases goal frequency as a standard of Max.
frequency/Min. frequency
1
Increases as many as step frequency according to edge input
2 Available to combine 1 and 2
In case of choosing F65 as a 1 or 2, it means increase or
decrease of frequency according to up-down input
0 Drive doesnʼt run as a draw mode
1 V1(0~10V) input draw run
2 I(0~20mA) input draw run
3 V1(-10~10V) input draw run
Sets rate of draw
During Decel
During constant run During Accel
Bit 2 Bit 1 Bit 0
0 - - -
1 - -
2 - -
3 -
4 - -
5 -
6 -
7
1 0
180 0
60 0
0 X
150 X
0 X
0.00 X
0 X
0.00 X
0 X
0.00 0
F56
F57
F58
F59
F60
F61
F63
F64
F65
F66
F70
F71
1)
2)
29
Compact & Powerful Drive iG5A
Drive Starvert iG5A Series
