1) Exception: Since SV004iG5A-2/SV004iG5A-4 is Natural convection type, this code is hidden.
1)
LED
display
Address for
communication
Parameter
name
Min/Max
range
Description
Adj.
during run
Factory
defaults
Function group 2
0 Settable unit: 0.01 second.
1 Settable unit: 0.1 second.
2 Settable unit: 1 second.
This parameter selects the parameter to be displayed on the
keypad when the input power is first applied.
0 Frequency command
1 Accel time
2 Decel time
3 Drive mode
4 Frequency mode
5 Multi-Step frequency 1
6 Multi-Step frequency 2
7 Multi-Step frequency 3
8 Output current
9 Motor rpm
10 Drive DC link voltage
11 User display select (H73)
12 Fault display
13 Direction of motor rotation select
14 Output current 2
15 Motor rpm 2
16 Drive DC link voltage 2
17 User display select 2
One of the following can be monitored via vOL - [User display
select].
0 Output voltage [V]
1 Output power [kW]
2 Torque [kgf,m]
This parameter is used to change the motor rotating speed (r/
min) to mechanical speed (m/mi) and display it.
0 Unlimited
1 Use DB resistor for the H76 set time.
Set the percent of DB resistor operating rate to be activated
during one sequence of operation.
0 Always ON
1
Keeps ON when its temp is higher than drive protection
limit temp. Activated only during operation when its temp
is below that of drive protection limit.
0 Continuous operation when cooling fan malfunctions.
1 Operation stopped when cooling fan malfunctions.
This parameter displays the drive software version.
1 O
0 O
0 O
100 O
1 O
10 O
0 O
0 O
1.0 X
H71
H72
H73
H74
H75
H76
H77
H78
H79
[Accel/Decel
A347
time scale]
0 ~ 2
A348
[Power on
0 ~ 15
display]
A349
[Monitoring
0 ~ 2
item select]
A34A
[Gain for Motor 1 ~ 1000
rpm display] [%]
[DB resistor
A34B operating rate 0 ~ 1
limit select]
A34C
[DB resistor 0 ~ 30
operating rate] [%]
A34D
[Cooling fan
0 ~ 1
control]
[Operating
A34E
method select
0 ~ 1
when cooling fan
malfunctions]
A34F [S/W version] 0 ~ 10.0
iG5A
Function List
34
To Next Page
