LSIS XEC-DN60SU

Chapter 5 Positioning Instructions
5 - 36
5.2.14 Positioning Speed Override Instruction
• The positioning speed override instruction (PSO) is changing the operation speed of the axis during
current positioning operation at the specific position set in the instruction. For details, refer to 3.1.10.
(1) Positioning speed override instruction (PSO)
[Area Setting]
Operand
Description
Setting range
Data size
sl Slot No. of positioning module XGB is fixed at 0 WORD
ax
Axis to give instruction
0 (axis X) or 1 (axis Y)
WORD
n1
Position to change the speed
-2,147,483,648 ~ 2,147,483,647
DINT
n2
Operation speed to change
0 ~ 100,000[pps]
DWORD
[Flag Set]
Flag Description Device number
Error If the value of ax gets out of the range F110
(a) Function
• This instruction is giving the positioning speed override instruction to XGB built-in positioning.
• The positioning speed override is executed at the axis designated as ax at the rising edge of the
input condition, and if the current position reaches the position set in n1 during operation, the
current operation speed is overridden to the speed set in n2.
• The positioning speed override instruction is available in the deceleration and acceleration
sections and if the positioning speed override is executed during deceleration or dwell, no error
code is issued, but the instruction is not executed either.
(b) Error
• If the value designated as ax (instruction axis) is other than 0 and 1, the error flag (F110) is set
and the instruction is not executed.
Instruction
Areas available
Step
Flag
PMK F L T C S Z D.x R.x
con
stan
t
U N D R
Error
(F110)
Zero
(F111)
Carry
(F112)
PSO
sl
-
-
-
-
-
-
-
-
-
○
-
-
-
-
4~7 ○ - -
ax ○ - ○ - - - ○ - - ○ - - ○ -
n1 ○ - ○ - - - ○ - - ○ - - ○ -
n2
○
-
○
-
-
-
○
-
-
○
-
-
○
-
PSO
COMMAND
PSO
sl ax n1 n2
