Lubecore 210 - Technical Information; Pneumatic Pump Technical Specifications

51
Technical Specifications
Table 8 – Pneumatic Pump Technical Specs
Part Number
50.050
50.060
Reservoir Capacity
4kg / 8.8lbs
6kg / 13.2lbs
Main Piston Air Grease Pressure Ratio
10:1
Maximum Grease Pressure
1600psi / 110bar
Pump Grease Output
40cc / stroke
Operated Temperature Range
-25°C to 80°C (-13°F to 160°F)
Lubricant Grade
NLGI-0
Dry Weight
12kg / 26.4lbs
13kg / 28.6lbs
Wet Weight
16kg / 35.2lbs
19kg / 41.8lbs
Follower Plate
Standard
Pressure Switch
Standard
Pressure Switch Rating
40bar / 580psi Standard
Low Level Switch / Sensor
Optional
Filler Coupling Size
¼”
Solenoid Voltage
12 or 24 VDC
Solenoid Wattage
3.6Watt
