Lucent Technologies LINEAGE 2000 ECS - Figure 1-2: VR Battery Supplementary Bay

Lucent Technologies Lineage
®
2000 ECS Battery Plant J85500D-3
Issue 5 January 1999 Introduction 1 - 5
Figure 1-2: VR Battery supplementary bay configurations
per J85504C-1
VR Series
Batteries
Universal VR Series
Battery Stand
8 Shelf Battery Stand 4 Shelf Battery Stand
