Lucent Technologies LINEAGE 2000 ECS - Figure 3-2 A: Bay Dimensions and Clearances (List 1 Equipped with List 9)

Lucent Technologies Lineage
®
2000 ECS Battery Plant J85500D-3
Issue 5 January 1999 Engineering, Planning and Ordering 3 - 43
Figure 3-2a: Bay Dimensions and Clearances (List 1
equipped with List 9)
No Wall Clearance
Required
19.68
DEPTH
30.00
AISLE CLEARANCE
86.67
HEIGHT
32.25
WIDTH
