Lucent Technologies LINEAGE 2000 ECS User Manual

Lucent Technologies Lineage
®
2000 ECS Battery Plant J85500D-3
3 - 38 Engineering, Planning and Ordering Issue 5 January 1999
Supplementary
components
(field installed)
Table 3-L lists field installed items needed to complete a total
battery plant system configuration. These items are ordered by
comcode and shipped separately.
Table 3-L: Supplementary Components (Field Installed)
Item
Quantity
Required
Description Comcode Wiring Information
Power Unit
A1 1 - 6 SR50/-48V Rectifier 107310187 N/A
IR Battery String Options
B1 4
12IR125 Battery
Order 4 for single string
Recommended float voltage -54.48V
407155399 T83280-30 Fig H1
B2
12IR125 Battery String Disconnect
(1 per battery string)
601793722 T83280-30 Fig HA
VR Battery String Options
D1
24
2VR375E Battery
Order 24 for a single 375AH string
Recommended float voltage -54.48V
407435825
T82670-31
T82671-30 Fig 1
3
Inter-Tier Cable Kit
ordered separately and always required
846808764
D2
24
2VR250E Battery
Order 24 for a single 250AH string
Recommended float voltage -52.21V
407435841
T82670-31
T82671-30 Fig 1
3
Inter-Tier Cable Kit
ordered separately and always required
846808764
D3
23
2VR375E Battery
Order 23 for a single 375AH string
Recommended float voltage -52.21V
407435825
T82670-31
T82671-30 Fig 11 Dummy Battery 407436518
3
Inter-Tier Cable Kit
ordered separately and always required
846808764
D4
23
2VR250E Battery
Order 23 for a single 250AH string
Recommended float voltage -52.21V
407435841
T82670-31
T82671-30 Fig 11 Dummy Battery 407436583
3
Inter-Tier Cable Kit
ordered separately and always required
846808764
D5
12
4VR125E Battery
Order 12 for a single 125AH string
Recommended float voltage -54.48V
407435858
T82670-31
T82671-30 Fig 1
1
Inter-Tier Cable Kit
ordered separately and always required
846808764
