Lucent Technologies Lineage

2000 ECS Battery Plant J85500D-3

2 - 8 Product Description Issue 5 January 1999

Figure 2-3: ECS distribution bus bars

K1 OR

STRAP

BATTERY

BUS 2

DISTRIBUTION BUS BARS

DO NOT EXCEED 200

AMPERE LOAD PER

BUS BAR

CHARGE

RETURN

BATTERY

BUS 1

TO LOAD

DISCHARGE RETURN

TO LOAD
