Lucent Technologies Lineage
®
2000 ECS Battery Plant J85500D-3
3 - 36 Engineering, Planning and Ordering Issue 5 January 1999
Note 103: The Record of Change Table traces when options are
added and discontinued on various drawing issues, as in Table C
of the T-drawing.
SD notes often contain important details on applications of
circuit features and options, so all notes should be read before
completing the engineering process.
G-sheets show Cabling Diagrams (CADs), define terminal
designations and wiring for installer connections. This
information is duplicated in the Installer Figures of the
T-drawing.
H-sheets are included in some SD-drawings to provide Block
Diagrams (BDs), helpful in understanding complex circuits.
J-sheets are used for Circuit Pack Schematics (CPSs), if any are
included in the SD. Most circuit packs, however, are
documented on separate schematic drawings, some of which are
proprietary and are not generally accessible.
Ordering
information
The J85500D-3 battery plant is ordered with List (L) numbers
(see Table 3-K).
A sample order for a D-3 plant containing five 50-ampere
rectifiers, a microprocessor board, (15) 20-ampere breakers, five
45-ampere breakers and (24) 48-volt, 375-ampere hour batteries,
one eight-shelf stand including two additional strings of
2VR375E VR batteries and battery cables would look like the
following. Note: “J” lists per J85500D-3 should be ordered as
separate line items. Format as “equipped with” (e/w) items.
ITEM QTY DESCRIPTION
1 1 J85500D-3 L-1 e/w L-2, L-3, (2) L-8, L-10
2 5 106673502 SR50/-48V rectifier
3 1 847366788 microprocessor board
4 15 407006352 20-Amp breaker
5 5 406746370 Amp breaker
6 3 407435825 2VR375E battery string
7 3 846481257 battery cable kit
8 1 J85504C-1 eight-shelf VR battery stand
